LDS Tank Bursting Warning Labels

Post by GiveMeABreak »

Attention C5 and C6 Owners

Another member of the Forum recently had his C5 X7 LDS tank explode at a recent tyre fitting session, when the vehicle was lowered back to the ground.

For those unaware, the C5 and C6 should have the suspension raised to the highest position and the LDS tank cap removed whenever the vehicle will be lifted off the ground with the wheels hanging freely and unsupported. Not doing so will allow uncontrolled fluid to be drawn from the tank into the suspension circuit under the weight of the wheels hanging. When the car is lowered the weight of the car will force all the fluid back into the tank in an uncontrolled manner, putting huge pressure on the system - but especially on the seam of the LDS tank. Over time this can weaken, where it will eventually burst with all the inevitable consequences.

Chris (white exec) has very kindly created some labels specifically for owners of the C5 and C6. Members may like to download and attach these somewhere appropriately on their LDS tank or Engine Bay, as a reminder to service personnel or fitters (or self!).

There is a larger one with more detailed wording that you may decide to put on the tank or in the engine bay. There is a smaller one that points to the larger label, which could for example be kept with the locking wheel nut which is needed for alloy wheel changes - or handed to the fitter / mechanic.

The PDF can be printed directly, or the images can be downloaded and imported into a document where you can have several laid out on a page for more copies. The printout can then be laminated and then cut to size for fixing onto your LDS tank or other suitable location.

The file is available as a PDF that contains both images, or you can download the images independently by clicking the links in the table.

Link to PDF Document Containing Both Labels

LDS Label Image Direct Downloads
Please Don't PM Me For Technical Help

Marc
User avatar
Skull
Donor 2024
Posts: 938
Joined: 02 Aug 2013, 13:35
Location: Darlington Co Durham
My Cars: Citroën Xantia XII HDi
Citroën AX XII

Missing AX 1.4D Echo
x 222

Re: LDS Tank Bursting Warning Labels

Post by Skull »

Thanks Chris and Marc 8-)
On my 4th Citroën Xantia (X2 HDi (110))
Citroën sAXo Memphis Mk II
Gone
Xantia x3 (2.0i TCT Activa)(2.1 TD SX)(1.9 TD Estate)
Xsara HDi VTR Coupe / Saxo 1.1i / BX 1.9 d / 4 x AX's (1.4D /1.5D)
2 x 406 (1.9 TD Estate/2.1 TD Saloon) 405 1.9 D Estate 306 1.9 XTDT Hatch
broomie
Posts: 77
Joined: 16 Aug 2004, 14:11
Location: United Kingdom
My Cars:
Contact:

Re: LDS Tank Bursting Warning Labels

Post by broomie »

superb effort many thanks printing now!
broomie (paulb)
Hell Razor5543
Donor 2023
Posts: 13726
Joined: 01 Apr 2012, 09:47
Location: Reading
My Cars: C5 Mk2 VTX+ estate.
x 2993

Re: LDS Tank Bursting Warning Labels

Post by Hell Razor5543 »

Nice job, Gentlemen. Might I make a suggestion though? On the C5 Mk1 the LDS reservoir is under a cover (off side, on a UK car). Would it be worth designing a label explaining that (and that the cap, if legible, indicates this is for the power steering)? I don't know if this would be the case for the facelift C5.
James
ex BX 1.9
ex Xantia 2.0HDi SX
ex Xantia 2.0HDi LX
Ex C5 2.0HDi VTR
Ex C5 2.0HDi VTR

C5 2.2HDi VTX+
Yes, I am paranoid, but am I paranoid ENOUGH?
Out amongst the stars, looking for a world of my own!
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: LDS Tank Bursting Warning Labels

Post by GiveMeABreak »

Just stick it on the plastic cover James, it still says “Citroen Hydractive” engraved on the plastic LDS cover on C5 MK I & IIs, so should be easy enough to work out.
Please Don't PM Me For Technical Help

Marc
Gibbo2286
(Donor 2020)
Posts: 7170
Joined: 08 Jun 2011, 18:04
Location: GL15***
My Cars: 2006 C5 2.0 Litre HDI VTR Automatic Estate.(now sold on)
Currently Renault Zoe 2014 ZE
x 2500

Re: LDS Tank Bursting Warning Labels

Post by Gibbo2286 »

This is a good idea but the problem is that the tyre fitters rarely open the bonnet or the boot before jacking the car up, maybe I could stick one on my forehead when meeting the fitter. :-D
Man is, by nature, a lazy beast, he does not need twice encouraging to do nothing.
User avatar
white exec
Moderating Team
Posts: 7445
Joined: 21 Dec 2015, 12:46
Location: Sayalonga, Malaga, Spain
My Cars: 1996 XM 2.5TD Exclusive hatch RHD
1992 BX19D Millesime hatch LHD
previously 1989 BX19RD, 1998 ZX 1.9D auto, 2001 Xantia 1.8i auto
and lots of Rovers before that: 1935 Ten, 1947 Sixteen, 1960 P5 3-litre, 1966 P6 2000, 1972 P6 2000TC, and 1975 P6B 3500S
x 1752

Re: LDS Tank Bursting Warning Labels

Post by white exec »

Did think about that.
If printed on some peelable labels, you could always whack one of the small ones on the wheel arch(es), for the duration of the job.

Did initially think of the small one as an alternative to one of the tiny Michelin tyre-pressure stickers once used on trucks and buses...
Chris
rmunns
Posts: 611
Joined: 09 Jul 2009, 22:09
Location: Southern Dordogne, France
My Cars: 2019 C5 Aircross 2litre diesel, auto.
2018 C4 Pic2 Spacetourer auto. Seems nice so far.
2019 C4 Cactus manual. Didn't like it, lots of niggling points. sold.
2011 C4 Picasso excl. - shaping up to be a disaster, bought June 2019. P/X'd
2009 Citroen C5 X7 exclusive, auto, LHD, 207500km (129000miles) now sold
Citroen Xsara Picasso excl. 2004 2.0 Hdi, RHD, 64000miles. (sold)
Citroen C3 Picasso excl. 2016. sold.
Two Xantias, one petrol, one diesel. sold.

In the past: Renault 16 (in about 1977, for a year). With front pass. seat out transported full bathroom suite from Cambridge to Derby!)
Renault 4TL (in 2011, for a year)
x 9

Re: LDS Tank Bursting Warning Labels

Post by rmunns »

Thanks.
mmatin
(Donor 2022)
Posts: 28
Joined: 16 Jan 2017, 10:45
Location: Linz, Austria
My Cars: C4 Grand Picasso 2.0 blueHDI 110 kW Exlusiv 2015

Re: LDS Tank Bursting Warning Labels

Post by mmatin »

Is this also procedure (highest position, LDS tank cap removed) if I want to change one wheel or if I lift just one side of the car (what my mechanic usually do).

Thanks for info in advance!
Mario Matin
User avatar
GiveMeABreak
Forum Admin Team
Posts: 36996
Joined: 15 Sep 2015, 19:38
Location: West Wales
My Cars: C3 Aircross SUV HDi Flair Peperoncino Red (The Chili Hornet)
C5 X7 2.0 HDi Exclusive Mativoire Beige (The Golden Hornet)
C3 1.6 HDi Exclusive Aluminium Grey (The Silver Hornet)
C5 MK II 2.0 HDi Exclusive Obsidian Black
C5 MK I 2.0 HDi SX Wicked Red
Xantia S2 2.0 HDi SX Hermes Red
C15 Romahome White
XM 2.0 Turbo Prestige Emerald Green Pearlescent
XM 2.0 Turbo Prestige Polar White
XM 2.0 SX Polar White
CX 20 Polar White
GS 1220 Geranium Red
CX 2.4 Prestige C-Matic Nevada Beige
GS 1000 Cedreat Yellow
x 5644

Re: LDS Tank Bursting Warning Labels

Post by GiveMeABreak »

One wheel should be fine, it is usually where all 4 wheels will be hanging freely that you need to be concerned, but I would always raise to high prior to jacking it up, and the same for 2 wheels.
Please Don't PM Me For Technical Help

Marc
mmatin
(Donor 2022)
Posts: 28
Joined: 16 Jan 2017, 10:45
Location: Linz, Austria
My Cars: C4 Grand Picasso 2.0 blueHDI 110 kW Exlusiv 2015

Re: LDS Tank Bursting Warning Labels

Post by mmatin »

Thanks for info Marc!
Mario Matin
admiral51
Donor 2023
Posts: 2625
Joined: 24 May 2007, 10:11
Location: poole dorset uk
Lexia Available: Yes
My Cars: C5 X7 2009 2.0 HDI VF7**************[VIN obfuscated, can be read by forum staff]
C4 2010 2.0 HDi Exclusive VF7**************[VIN obfuscated, can be read by forum staff]
x 378

Re: LDS Tank Bursting Warning Labels

Post by admiral51 »

Has anyone reached out to the Major Tyre Fitting Companies to see if they are aware of this issue.

Just an idle thought as i guess there are many Citroen owners that are not members of this forum or any other ?
Online
User avatar
myglaren
Forum Admin Team
Posts: 25362
Joined: 02 Mar 2008, 13:30
Location: Washington
My Cars: Mazda 6
Ooops.
Previously:
2009 Honda Civic :(
C5, C5, Xantia, BX, GS, Visa.
R4, R11TXE, R14, R30TX
x 4888

Re: LDS Tank Bursting Warning Labels

Post by myglaren »

I did mention it to the MOT/tyre fitter when I went for tracking adjustment and they were well aware of it.
Not a national chain though.
User avatar
Stickyfinger
(Donor 2016)
Posts: 10411
Joined: 28 Mar 2013, 21:05
Location: Somset my lovleee
My Cars: Xantia V6 ACTIVA 3ltr 24v Manual p1
Xm 2.1TD Ph2 Exclusive
AX, little Daffodil
SAXO White Mk1. Sally
x 1280
Contact:

Re: LDS Tank Bursting Warning Labels

Post by Stickyfinger »

It is on the MoT testers "Opening Notes" as they sign a C5 into the system.

Tyre "shops"......NEVER leave a C5 with any of them.
Alasdair
Activa, the Moose Rider
3x C5x7 Steering racks and counting
Jay-Bruce
(Donor 2022)
Posts: 509
Joined: 20 Mar 2019, 00:30
Location: North East Scotland
My Cars: BMW 635D
Citroen C5 Tourer (X7) 3.0HDi Exclusive
407 Coupe 2.7vh HDI
206 gti180
206 GranTurisme (Sold)
BX Gti16V (Phase2)
x 241

Re: LDS Tank Bursting Warning Labels

Post by Jay-Bruce »

I am glad I read this, I've got my own workshop and was going to lift our c5 (x7) to take the wheels off and balance them, Had I not read this thread I'd have most likely eploded our cars tank.
